Corazon Pipes and Tubes is a trusted manufacturer and supplier of Titanium Coil Tubing, proudly based in Manila, Philippines. They specialize in high-performance tubing that’s perfect for demanding, continuous-length applications. Their titanium coil tubes are crafted with precision, featuring tight tolerances, excellent roundness, and clean internal surfaces to promote efficient flow and a long service life. Renowned for their superior corrosion resistance, lightweight strength, and outstanding mechanical stability, these tubes are ideal for critical operations in chemical processing, marine systems, oil and gas, and heat transfer equipment. Corazon Pipes and Tubes ensures their coil tubing meets rigorous global standards for durability, efficiency, and consistent performance.
Titanium Coil Tubing is made from commercially pure titanium or titanium alloys, which include carefully controlled amounts of oxygen, nitrogen, carbon, hydrogen, and iron. In alloyed grades, elements like aluminum and vanadium are also included. This specific composition guarantees high corrosion resistance, an excellent strength-to-weight ratio, and biocompatibility. On the mechanical side, titanium coil tubes provide good tensile and yield strength, impressive fatigue resistance, and stability even at elevated temperatures. Their flexibility, toughness, and low density make them perfect for long, continuous runs and high-pressure operations where durability, precision, and corrosion protection are essential.
| Standard | ASTM, AISI, GB, JIS, customers’ requests available |
| Size | Round Tube: OD: 16-119mm or customized |
| Thickness | 0.25mm-3.0mm |
| Length | 6m or according to customers’ request |
| Sample | Free sample is available, but freight should be paid by you |
Tolerance
| Outer diameter: ±0.2mm |
| Thickness: ±0.05mm | |
| Length: ±0.5mm | |
| Ends | In plain end or bevelled ends or as your requirements |
| Welding Line Type | ERW (Electrical Resistance Weld) |
Finishing
| A. Sanded |
| B. Gloss #400,Mirror #600 – #1000 | |
| C. Brushed | |
| D. Wood Grain | |
| E. Embossed, Threaded | |
| Application | Decorations, constructions, food industry, etc. |
| Certification | ISO, SGS |
| Round Pipe Size | 16, 17, 18, 19, 20, 21, 22, 23, 25, 28, 31.8, 35, 36, 38.1, 48, 50.8, 60, 63.5, 76.2, 89, 101, 114 mm |
| Square Pipe Size | 17, 18, 19, 20, 21, 22, 23, 24, 25, 28, 30, 36, 38, 50 mm |
| Rectangle Pipe Size | 10*30, 10*40, 10*50, 20*10, 23*11, 24*12, 25*13, 28*25, 28*13, 29*14, 30*15, 30*20, 30*22, 34*22, 36*23, 50*25, 60*30, 75*45, 95*45 mm |
| Thickness | exact 0.25, 0.28, 0.32, 0.37, 0.41, 0.51, 0.61, 0.71, 0.91, 1.11, 1.15, 1.41 mm |
| Length | 6m or according to customer’s request |
| Outer diameter | 6.35-219mm |
| Tolerance | Outer diameter :±0.2mm |
| Thickness :±0.02mm | |
| Length :±0.5mm | |
| Process method | Code drawn, annealed with nitrogen protection, ultrasonic, automatic shape, polished |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine Sand-blasting machine, etc |
| Origin | West Europe / Japanese / Indian / USA / Korean / American / European |
| Test Certificates | Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
By choosing Titanium Coil Tubing from Corazon Pipes and Tubes, you are assured of superior quality and durability. These tubes provide outstanding corrosion resistance and strength, making them ideal for a wide range of industrial applications. Our dedication to excellent service and dependable delivery ensures customer satisfaction every time. With our expertise in stainless steel products, we deliver top-tier solutions customized to meet your specific requirements.
Corazon Pipes and Tubes, a leading supplier of Titanium Coil Tubing in Manila, Philippines, provides a wide selection of premium pipes and tubes for diverse industrial applications. With a vast inventory and a strong focus on delivering outstanding service, they are the preferred choice for stainless steel products in the region.
At Corazon Pipes and Tubes, we provide custom sizes of Titanium Coil Tubing to meet your exact specifications. Our dedicated team is here to offer tailored solutions for all your piping and tubing needs. For more information, feel free to reach out to us at sales@brydonpipesandtubes.co.uk.
Titanium Coil Tubing finds its place in various industries that demand long, continuous, corrosion-resistant tubing with exceptional mechanical performance. In chemical processing, it’s utilized for heat exchangers, cooling coils, and lines for transferring corrosive fluids. The oil and gas industry relies on titanium coil tubing for hydraulic control lines, downhole systems, and chemical injection units, thanks to its lightweight strength and ability to withstand harsh environments. Additionally, the marine and desalination sectors depend on it for seawater coolers, condensers, and brine applications, making it a versatile choice across multiple fields.
