Home > Carbon Steel > J356 Tubing
J356 tubing is a type of low-carbon steel tubing that’s mainly used in making hydraulic and pneumatic systems. It’s often chosen for applications that need medium strength, good formability, and resistance to corrosion, especially in environments where it won’t face extreme corrosion factors. Typically, J356 tubing has a smooth surface and is great for transporting fluids and gases in systems where durability and reliability are crucial. You’ll find it widely used in automotive, industrial machinery, and construction settings, where both cost-effectiveness and performance are top priorities.
The J356 tubing we produce is defined by its specific composition and strength. It’s crafted from a carbon steel base, ensuring a solid balance of formability and durability. Mechanically, this tubing is known for its excellent tensile strength and good weldability, making it a practical and resilient choice for fabricators. This combination of properties means it can handle significant pressure and stress, offering a reliable performance that stands up to the demands of various industrial applications without compromising on workability.
| Grade: | ASME/ASTM SA179, SA192, SA210, SA178, SA214, API 5L |
|---|---|
| Size: | 1/8” NB TO 24” NB Sch 40/80/160/XXS |
| Form | Round, Square, Rectangular, Coil, U Tube, |
| Length | Single Random, Double Random & Required Length |
| End | Plain End, Bevelled End |
| Type | Seamless / ERW / Welded |
| Certification For Carbon | Mill Test Certificate as per EN 10204 / 3.2B |
| General Requirements | ASTM A 530/A 530M |
| Dimensional Tolerances | ANSI B 36.10 |
| OD Range | 1.250″ – 6.000″ (30-150mm) |
| Wall Range | 0.095″ – 1.000″ (.2.5-25mm) |
| CHEMICAL REQUIREMENTS | ||
| Element | Cast or Heat Analysis: Weight % | |
| J356 | J356 Type-A | |
| Carbon | 0.06 Min/0.18 Max | 0.02 Min/0.18 Max |
| Manganese | 0.30 Min/0.60 Max | 0.10 Min/0.60 Max |
| Phosphorus | 0.04 Max | 0.04 Max |
| Sulfur | 0.06 Max | 0.05 Max |
| MECHANICAL PROPERTIES | |
| Properties | Values |
| Yield Strength (Min) | 25,000 PSI |
| Tensile Strength (Min.) | 45,000 PSI |
| Elongation in 2” (Min) | 35% a |
| Hardness (Rockwell B)(Max) | 65 b |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
When it comes to its composition, J356 tubing is primarily made up of carbon (around 0.25-0.30%), along with small amounts of manganese, phosphorus, and sulfur. The low carbon content gives it good weldability and makes it easy to work with while still providing enough strength for most industrial uses. In terms of mechanical properties, J356 tubing boasts good tensile strength (usually between 350-450 MPa) and moderate yield strength (around 200 MPa). It also has higher ductility compared to other higher-carbon steels, which means it can be bent and shaped without cracking. Plus, J356 is known for its durability in industrial applications.
Corazon Pipes and Tubes, one of the largest suppliers of J356 Tubing in Manila, Philippines, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
You’ll find J356 tubing primarily in hydraulic systems, like those in construction machinery, industrial equipment, and automotive brake lines. Its high formability and moderate strength make it perfect for these uses, where fluid or gas needs to be transmitted under pressure. It’s also commonly found in pneumatic systems, where air or gas needs to be moved with minimal risk of leaks or ruptures. Additionally, J356 tubing is used in applications that require precise dimensions and a good surface finish, such as fuel lines and fluid handling systems. Its combination of strength, ease of fabrication, and affordability makes it a go-to choice across various industries.
**J356 Tubing** is extensively utilized in automotive and aerospace sectors for hydraulic and fuel systems, mechanical assemblies, and structural components. It’s also a go-to choice in chemical and petrochemical plants for process piping and fluid handling under moderate to high pressure. Furthermore, J356 Tubing is found in industrial machinery, manufacturing equipment, and precision engineering systems where strength, fatigue resistance, and corrosion performance are vital. The blend of mechanical strength, durability, and reliability makes J356 Tubing an essential component in various industrial applications.
