Based in the industrious heart of Manila, Philippines, Corazon Pipes and Tubes has built a reputation as a trusted partner for demanding industrial applications. We specialize in providing high-performance materials, including our robust Monel boiler tubing. Understanding the critical nature of boiler systems, we ensure our Monel tubes offer the resilience and longevity needed for such high-stakes environments. Our commitment is to deliver not just a product, but a reliable solution that supports the operational integrity and safety of your projects across the Philippines and beyond.
This particular tubing is crafted from Monel, a nickel-copper alloy renowned for its exceptional strength and unwavering resistance to corrosion. It stands up remarkably well to a wide range of challenging conditions, from corrosive chemicals to fast-moving seawater and even high-temperature steam. The material maintains excellent mechanical properties, including good tensile strength and superior ductility, even under thermal stress. This combination means the tubing is not only tough but also reliably durable, performing consistently in environments that would quickly degrade lesser materials.
| Boiler Tube Standard | ASTM B163, B730 / ASME SB163, SA730 |
| Seamless Boiler Tube Sizes | 1 / 2″ NB – 16″ NB |
| Welded Boiler Tube Sizes | 1 / 2″ NB – 24″ NB |
| Boiler Tube Outside Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Boiler Tubes available Ex-stock |
| Boiler Tube Manufacturing Process | Seamless / Welded / ERW |
| Monel Boiler Tube Schedule | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Boiler Tube Length | Single Random, Double Random, Standard & Cut length |
| Delivery Condition | Annealed and Pickled, Polished, Bright Annealed, Cold Drawn |
| Outside Finish | 2B, No.4, No.1, No.8 Mirror Finish for Monel Boiler Tubes, Finish as per customer Requirements |
| Value Added Services | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| BWG | BWG | BWG | BWG | BWG | BWG | BWG | BWG | ||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||
| WT mm | WT mm | WT mm | WT mm | WT mm | WT mm | WT mm | WT mm | ||
| Outside Diameter | Outside Diameter | 0.508 | 0.711 | 0.889 | 1.245 | 1.651 | 2.108 | 2.769 | 3.404 |
| mm | inch | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | |
| 6.35 | 1/4 | 0.081 | 0.109 | 0.133 | 0.174 | 0.212 | |||
| 9.53 | 3/8 | 0.126 | 0.157 | 0.193 | 0.257 | 0.356 | 0.429 | ||
| 12.7 | 1/2 | 0.214 | 0.263 | 0.356 | 0.457 | 0.612 | 0.754 | ||
| 15.88 | 5/8 | 0.271 | 0.334 | 0.455 | 0.588 | 0.796 | 0.995 | ||
| 19.05 | 3/4 | 0.327 | 0.405 | 0.553 | 0.729 | 0.895 | 1.236 | ||
| 25.4 | 1 | 0.44 | 0.546 | 0.75 | 0.981 | 1.234 | 1.574 | 2.05 | |
| 31.75 | 1 1/4 | 0.554 | 0.688 | 0.947 | 1.244 | 1.574 | 2.014 | 2.641 | |
| 38.1 | 1 1/2 | 0.667 | 0.832 | 1.144 | 1.514 | 1.904 | 2.454 | 3.233 | |
| 44.5 | 1 3/4 | 1.342 | 1.774 | 2.244 | 2.894 | 3.5 | |||
| 50.8 | 2 | 1.549 | 2.034 | 2.574 | 3.334 | 4.03 | |||
| 63.5 | 2 1/2 | 1.949 | 2.554 | 3.244 | 4.214 | 5.13 | |||
| 76.2 | 3 | 2.345 | 3.084 | 3.914 | 5.094 | 6.19 | |||
| 88.9 | 3 1/2 | 2.729 | 3.609 | 4.584 | 5.974 | 7.27 | |||
| 101.6 | 4 | 4.134 | 5.254 | 6.854 | 8.35 | ||||
| 114.3 | 4 1/2 | 4.654 | 5.924 | 7.734 | 9.43 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Monel Boiler Tubing from Corazon Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our tubing is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
Corazon Pipes and Tubes, one of the largest suppliers of Monel Boiler Tubing in Manila, Philippines, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Our extensive inventory and commitment to exceptional service make us the go-to choice for Monel products in the region.
Yes, we offer custom sizes for Monel Boiler Tubing to meet your specific requirements. Our team at Corazon Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@corazonpipes.com.
Monel Boiler Tubing finds extensive use in steam boilers, heat exchangers, condensers, and piping systems across the chemical, marine, and power industries. Its outstanding resistance to corrosion and high-temperature strength makes it well-suited for seawater and acidic environments. These tubes are also employed in desalination plants, offshore oil rigs, and industrial processing units where durability and reliability are crucial. Monel Boiler Tubing is perfect for managing high-pressure steam, hot water, and other aggressive fluids. Corazon Pipes’ precision manufacturing ensures that these tubes meet the demanding needs of various applications.
