Home > Incoloy > Incoloy Boiler Tubing
Nestled in the industrial heart of Manila, Corazon Pipes and Tubes has built a solid reputation as a trusted supplier for demanding applications. We understand that the heart of any efficient boiler system lies in its tubing, which is why we provide premium Incoloy solutions. Our commitment is to ensure that your operations benefit from tubing that offers not just resilience, but also exceptional performance under extreme conditions, safeguarding your systems for the long term.
The composition of Incoloy alloy, primarily nickel, chromium, and iron, is expertly balanced with additions like molybdenum and copper. This careful formulation grants the boiler tubing remarkable strength and the ability to withstand intense pressures. More importantly, it exhibits outstanding resistance to corrosion, particularly from harsh environments like those containing chlorides, making it a reliable choice for challenging conditions.
| Boiler Tube Standard | ASTM B423, B739 / ASME SB423, SA516 |
| Seamless Boiler Tube Sizes | 1 / 2″ NB – 16″ NB |
| Welded Boiler Tube Sizes | 1 / 2″ NB – 24″ NB |
| Boiler Tube Outside Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Boiler Tubes available Ex-stock |
| Boiler Tube Manufacturing Process | Seamless / Welded / ERW |
| Incoloy Boiler Tube Schedule | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Boiler Tube Length | Single Random, Double Random, Standard & Cut length |
| Delivery Condition | Annealed and Pickled, Polished, Bright Annealed, Cold Drawn |
| Outside Finish | 2B, No.4, No.1, No.8 Mirror Finish for Incoloy Boiler Tubes, Finish as per customer Requirements |
| Value Added Services | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Incoloy Boiler Tubes from Corazon Pipes and Tubes ensures superior quality and durability, offering outstanding corrosion resistance and high strength. Our dedication to delivering exceptional service and reliable products guarantees customer satisfaction across a wide range of industrial applications. With our expertise in Incoloy solutions, you can trust us to provide a top-tier, customized piping solution that meets your specific requirements.
Corazon Pipes and Tubes, one of the largest suppliers of Incoloy Boiler Tubing in the Manilas, Philippines. Offers a wide range of high-quality pipes and tubes designed for various industrial applications. Their extensive inventory and dedication to exceptional service make them a trusted choice for Incoloy products in the region, delivering reliable solutions to meet diverse project requirements.
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
| BWG | BWG | BWG | BWG | BWG | BWG | BWG | BWG | ||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||
| WT mm | WT mm | WT mm | WT mm | WT mm | WT mm | WT mm | WT mm | ||
| Outside Diameter | Outside Diameter | 0.508 | 0.711 | 0.889 | 1.245 | 1.651 | 2.108 | 2.769 | 3.404 |
| mm | inch | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | kgs/m | |
| 6.35 | 1/4 | 0.081 | 0.109 | 0.133 | 0.174 | 0.212 | |||
| 9.53 | 3/8 | 0.126 | 0.157 | 0.193 | 0.257 | 0.356 | 0.429 | ||
| 12.7 | 1/2 | 0.214 | 0.263 | 0.356 | 0.457 | 0.612 | 0.754 | ||
| 15.88 | 5/8 | 0.271 | 0.334 | 0.455 | 0.588 | 0.796 | 0.995 | ||
| 19.05 | 3/4 | 0.327 | 0.405 | 0.553 | 0.729 | 0.895 | 1.236 | ||
| 25.4 | 1 | 0.44 | 0.546 | 0.75 | 0.981 | 1.234 | 1.574 | 2.05 | |
| 31.75 | 1 1/4 | 0.554 | 0.688 | 0.947 | 1.244 | 1.574 | 2.014 | 2.641 | |
| 38.1 | 1 1/2 | 0.667 | 0.832 | 1.144 | 1.514 | 1.904 | 2.454 | 3.233 | |
| 44.5 | 1 3/4 | 1.342 | 1.774 | 2.244 | 2.894 | 3.5 | |||
| 50.8 | 2 | 1.549 | 2.034 | 2.574 | 3.334 | 4.03 | |||
| 63.5 | 2 1/2 | 1.949 | 2.554 | 3.244 | 4.214 | 5.13 | |||
| 76.2 | 3 | 2.345 | 3.084 | 3.914 | 5.094 | 6.19 | |||
| 88.9 | 3 1/2 | 2.729 | 3.609 | 4.584 | 5.974 | 7.27 | |||
| 101.6 | 4 | 4.134 | 5.254 | 6.854 | 8.35 | ||||
| 114.3 | 4 1/2 | 4.654 | 5.924 | 7.734 | 9.43 |
Yes, we provide custom sizes for Incoloy Boiler Tubes to meet your specific requirements. At Corazon Pipes and Tubes, our team is dedicated to delivering tailored solutions for all your piping and tubing needs. For more information, please contact us at sales@corazonpipes.com.
Incoloy Boiler Tubing finds extensive use in boilers, heat exchangers, and high-temperature piping systems across the chemical, petrochemical, and power generation industries. It’s perfect for superheater tubes, economizers, furnace tubing, and other applications that require high pressure and temperature. Its outstanding corrosion resistance and mechanical strength guarantee reliable performance in environments that face steam, aggressive chemicals, and thermal cycling. Engineers and designers depend on this tubing to ensure safety and efficiency in their projects.
