Home > Incoloy > Incoloy Coil Tubing
Based in the vibrant industrial landscape of Manila, Corazon Pipes and Tubes has built a reputation as a trusted partner for demanding industries. We are dedicated to providing high-performance materials, with our Incoloy coil tubing standing out as a prime example of our commitment. Our team understands the critical nature of your projects, which is why we ensure our coil tubing offers not just superior materials but also the flexibility and reliability needed for complex installations and harsh environments.
The strength of Incoloy coil tubing comes from its sophisticated composition, typically a nickel-iron-chromium alloy enriched with molybdenum and copper. This blend gives it truly impressive mechanical properties, including outstanding tensile strength and remarkable resistance to creep and fatigue. Most importantly, it retains this robustness even when exposed to the intense heat that would cause other materials to fail, making it a consistently dependable choice.
| Thickness | 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Outer Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB |
| Type | Seamless / ERW / Welded / Fabricated / CDW |
| Form | Round Tubes, Square Tubes, Rectangular Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes |
| Length | Single Random, Double Random & Required Length |
| End | Plain End, Beveled End, Treaded. |
Properties | Metric | Imperial |
Density | 8.14 g/cm³ | 0.294 lb/in³ |
Melting point | 1385°C | 2525°F |
|
Element |
Content (%) |
|
Nickel, Ni |
38-46 |
|
Iron, Fe |
22 |
|
Chromium, Cr |
19.5-23.5 |
|
Molybdenum, Mo |
2.50-3.50 |
|
Copper, Cu |
1.50-3.0 |
|
Manganese, Mn |
1 |
|
Titanium, Ti |
0.60-1.20 |
|
Silicon, Si |
0.50 |
|
Aluminum, Al |
0.20 |
|
Carbon, C |
0.050 |
|
Sulfur, S |
0.030 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Incoloy Coil Tubes from Corazon Pipes and Tubes ensures superior quality and durability, offering outstanding corrosion resistance and high strength. Our dedication to delivering exceptional service and reliable products guarantees customer satisfaction across a wide range of industrial applications. With our expertise in Incoloy solutions, you can trust us to provide a top-tier, customized piping solution that meets your specific requirements.
Corazon Pipes and Tubes, one of the largest suppliers of Incoloy Coil Tubing in the Manilas, Philippines. Offers a wide range of high-quality pipes and tubes designed for various industrial applications. Their extensive inventory and dedication to exceptional service make them a trusted choice for Incoloy products in the region, delivering reliable solutions to meet diverse project requirements.
|
Properties |
Metric |
Imperial |
|
Tensile strength (annealed) |
690 MPa |
100000 psi |
|
Yield strength (annealed) |
310 MPa |
45000 psi |
|
Elongation at break (annealed prior to test) |
45% |
45% |
|
Properties |
Metric |
Imperial |
|
|
Thermal expansion co-efficient (at 20-100°C/68-212°F) |
14 µm/m°C |
7.78 µin/in°F |
|
|
Thermal conductivity |
11.1 W/mK |
77 BTU in/hr.ft².°F |
|
Yes, we provide custom sizes for Incoloy Coil Tubes to meet your specific requirements. At Corazon Pipes and Tubes, our team is dedicated to delivering tailored solutions for all your piping and tubing needs. For more information, please contact us at sales@corazonpipes.com.
Incoloy Coil Tubing finds its place in various industries that need corrosion-resistant and flexible piping solutions. You’ll often see it in heat exchangers, condensers, chemical and petrochemical plants, marine systems, and power generation facilities. The coiled design facilitates efficient installation in cramped spaces, minimizing the need for complicated fittings and joints. It’s also utilized in reactors, process piping, and thermal systems that face high temperatures and aggressive chemicals. Engineers trust Corazon Pipes for reliable solutions that meet their demanding needs.
