Home > Stainless Steel > Stainless Steel 316H Heat Exchanger Tubing
Based in the industrious heart of Manila, Corazon Pipes and Tubes has built a reputation as a trusted partner for specialized industrial materials. We take particular pride in our expertise with Stainless Steel 316H Heat Exchanger Tubing, a product where precision and purity are paramount. Our focus is on delivering tubing that not only meets but exceeds rigorous standards, ensuring your critical heat transfer systems are built on a foundation of absolute reliability and performance, right from our local hub to your project.
The strength of 316H tubing lies in its carefully balanced composition, which includes chromium, nickel, and a higher carbon content than standard 316L. This specific recipe gives it superior mechanical properties, especially when facing high temperatures. The material retains remarkable tensile strength and excellent resistance to creep, meaning it can withstand prolonged stress and intense heat without deforming, making it a durable and dependable choice for demanding thermal applications.
Range : 10 mm OD to 50.8 mm OD
Outer Diameter : 6.00 mm to 101.60 mm
Wall Thickness : 0.70 mm to 8.00 mm
Length : up to 20 m (65.62 ft) Length & Customed Required Length
Specifications : ASTM A 213, A 268, A 269, A 789, Equivalent to ASME, EN, JIS Etc.
| Element | SS 316H |
| C | 0.10 max |
| Mn | 2.0 max |
| Si | 0.75 max |
| P | 0.045 max |
| S | 0.030 max |
| Cr | 16.00 – 18.00 |
| Mo | 2.00 – 3.00 |
| Ni | 10.00 – 14.00 |
| Fe | 68.89 min |
| Element | SS 316H |
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel 316H Heat Exchanger Tubing from Corazon Pipes and Tubes ensures superior quality and reliability. With expertise in precision manufacturing, Corazon Pipes and Tubes provides 316H tubing that offers exceptional strength and corrosion resistance, especially in high-temperature and corrosive environments. Their products meet stringent industry standards, ensuring long-lasting performance in demanding applications. Additionally, Corazon Pipes and Tubes is known for timely deliveries, excellent customer service, and customized solutions, making them a trusted supplier for industries like chemical processing, power generation, and oil and gas.
Corazon Pipes and Tubes, one of the largest suppliers of Stainless Steel 316H Heat Exchanger Tubing in Manila, Philippines, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Stainless Steel 316H Heat Exchanger Tubing to meet your specific requirements. Our team at Corazon Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@corazonpipes.com.
| STANDARD | WERKSTOFF NR. | UNS | JIS |
| SS 316H | 1.4401 | S31609 | SUS 316H |
You’ll find Stainless Steel 316H Heat Exchanger Tubing widely used in heat exchangers, condensers, boilers, and pressure vessels across the chemical and petrochemical sectors, as well as in oil and gas refineries and power plants. Its outstanding corrosion resistance and ability to handle high temperatures make it a go-to for marine, pharmaceutical, and food processing applications where hygiene and durability are paramount. Moreover, it’s utilized in water treatment plants, desalination facilities, and other high-performance systems that require reliability under thermal stress. This tubing guarantees efficient heat transfer, structural integrity, and long-lasting performance even in the most challenging environments.
